抱歉，該產品已停產下架
產品特點：
? 定倍工業鏡頭，有對卷工作距/倍率供選擇
? 直徑?16mm超小巧外觀設計，狹小空間適用
? 設有內置同軸光及超過倍率規格，與同行各款鏡頭兼容
? 性價比突出，大幅降低了工業影像及機器視覺的應用門檻
型號
| 光學參數
| 鏡頭外形
| 像方視場(W x H)
|
倍率
| 景深
| 分辨率μm
| 長度
| Zui大外徑
| 1/4" 像面
| 1/3" 像面
| 1/2" 像面
|
CSWL08-65AT
| 0.8x
| 2.9
| 19.9
| 76
| 16
| 4x3
| 6x4.5
| 8x6
|
CSWL10-65AT
| 1.0x
| 1.1
| 10
| 80
| 16
| 3.2 x 2.4
| 4.8 x 3.6
| 6.4 x 4.8
|
CSWL15-65AT
| 1.5x
| 0.55
| 7
| 74.6
| 16
| 2.1x1.6
| 3.2x2.4
| 4.3x3.2
|
CSWL20-65AT
| 2.0x
| 0.33
| 5.6
| 80.1
| 16
| 1.6x1.2
| 2.4x1.8
| 3.2x2.4
|
CSWL30-65A
| 3.0x
| 0.26
| 6.7
| 75
| 16
| 1.1x0.8
| 1.6x1.2
| 2.1x1.6
|
CSWL40-65A
| 4.0x
| 0.19
| 6.2
| 103.8
| 16
| 0.8x0.6
| 1.2x0.9
| 1.6x1.2
|
CSWL08-65CT
| 0.8x
| 3
| 20
| 76
| 16
| 4x3
| 6x4.5
| 8x6
|
CSWL10-65CT
| 1.0x
| 1.18
| 10
| 80
| 16
| 3.2 x 2.4
| 4.8 x 3.6
| 6.4 x 4.8
|
CSWL15-65CT
| 1.5x
| 0.55
| 7
| 74.6
| 16
| 2.1x1.6
| 3.2x2.4
| 4.3x3.2
|
CSWL20-65CT
| 2.0x
| 0.33
| 5.6
| 80.1
| 16
| 1.6x1.2
| 2.4x1.8
| 3.2x2.4
|
CSWL30-65C
| 3.0x
| 0.27
| 7
| 75
| 16
| 1.1x0.8
| 1.6x1.2
| 2.1x1.6
|
CSWL40-65C
| 4.0x
| 0.19
| 6.2
| 103.8
| 16
| 0.8x0.6
| 1.2x0.9
| 1.6x1.2
|
CSWL05-110AT
| 0.5x
| 3
| 25.4
| 106.3
| 29
| 7.2x4.8
| 9.6x7.2
| 12.8x9.6
|
CSWL05-110CT
| 0.5x
| 3
| 25.4
| 106.3
| 29
| 7.2 x4.8
| 9.6 x 7.2
| 12.8 x 9.6
|
CSWL08-130AT
| 0.8x
| 2.9
| 19.7
| 97.1
| 18
| 4x3
| 6x4.5
| 8x6
|
CSWL10-110AT
| 1.0x
| 1.5
| 13.2
| 109.8
| 16
| 3.2 x 2.4
| 4.8 x 3.6
| 6.4 x 4.8
|
CSWL15-110A
| 1.5x
| 0.5
| 6.7
| 104.2
| 16
| 2.1x1.6
| 3.2x2.4
| 4.3x3.2
|
CSWL20-110ATS
| 2.0x
| 0.7
| 12.9
| 73.8
| 16
| 1.6x1.2
| 2.4x1.8
| 3.2x2.4
|
CSWL25-110A
| 2.5x
| 0.3
| 8.2
| 109.7
| 16
| 1.28x0.96
| 1.92x1.44
| 2.56x1.92
|
CSWL30-110AT
| 3.0x
| 0.3
| 7.8
| 117.1
| 16
| 1.1x0.8
| 1.6x1.2
| 2.1x1.6
|
CSWL40-110A
| 4.0x
| 0.2
| 7.3
| 132.5
| 16
| 0.8x0.6
| 1.2x0.9
| 1.6x1.2
|
CSWL08-130CT
| 0.8x
| 2.9
| 19.7
| 97.1
| 18
| 4x3
| 6x4.5
| 8x6
|
CSWL10-110CT
| 1.0x
| 1.5
| 13.2
| 109.8
| 16
| 3.2 x 2.4
| 4.8 x 3.6
| 6.4 x 4.8
|
CSWL15-110C
| 1.5x
| 0.5
| 6.7
| 104.2
| 16
| 2.1x1.6
| 3.2x2.4
| 4.3x3.2
|
CSWL20-110CTS
| 2.0x
| 0.6
| 11.2
| 73.8
| 16
| 1.6x1.2
| 2.4x1.8
| 3.2x2.4
|
CSWL25-110C
| 2.5x
| 0.38
| 8.2
| 109.7
| 16
| 1.28x0.96
| 1.92x1.44
| 2.56x1.92
|
CSWL30-110CT
| 3.0x
| 0.3
| 7.8
| 117.1
| 16
| 1.1x0.8
| 1.6x1.2
| 2.1x1.6
|
CSWL40-110C
| 4.0x
| 0.2
| 7.3
| 132.5
| 16
| 0.8x0.6
| 1.2x0.9
| 1.6x1.2
|
CSWL08-150A
| 0.8x
| 3.3
| 22.7
| 80
| 16
| 4x3
| 6x4.5
| 8x6
|
CSWL10-150AT
| 1.0x
| 2.1
| 24
| 90.1
| 16
| 3.2 x 2.4
| 4.8 x 3.6
| 6.4x4.8
|
CSWL15-150AT
| 1.5x
| 0.9
| 12
| 90.2
| 16
| 2.1x1.6
| 3.2x2.4
| 4.3x3.2
|
CSWL20-150AT
| 2.0x
| 0.7
| 12
| 102.6
| 16
| 1.6x1.2
| 2.4x1.8
| 3.2x2.4
|
CSWL30-150AT
| 3.0x
| 0.4
| 10.8
| 128.8
| 16
| 1.1x0.8
| 1.6x1.2
| 2.1x1.6
|
CSWL40-150A
| 4.0x
| 0.2
| 8.2
| 172.4
| 16
| 0.8x0.6
| 1.2x0.9
| 1.6x1.2
|
CSWL10-150CT
| 1.0x
| 2.1
| 18.6
| 90.1
| 16
| 3.2 x 2.4
| 4.8 x 3.6
| 6.4x4.8
|
CSWL15-150CT
| 1.5x
| 0.9
| 12
| 90.2
| 16
| 2.1x1.6
| 3.2x2.4
| 4.3x3.2
|
CSWL20-150CT
| 2.0x
| 0.7
| 12.2
| 102.6
| 16
| 1.6x1.2
| 2.4x1.8
| 3.2x2.4
|
CSWL30-150CT
| 3.0x
| 0.4
| 10.8
| 128.8
| 16
| 1.1x0.8
| 1.6x1.2
| 2.1x1.6
|
CSWL40-150C
| 4.0x
| 0.2
| 8.2
| 172.4
| 16
| 0.8x0.6
| 1.2x0.9
| 1.6x1.2
|
CSWL08-250A
| 0.8x
| 2.2
| 15
| 89.5
| 16
| 4x3
| 6x4.5
| 8x6
|
CSWL10-250A
| 1.0x
| 1.6
| 13.4
| 115.8
| 16
| 3.2 x 2.4
| 4.8 x 3.6
| 6.4x4.8
|
CSWL15-250A
| 1.5x
| 1
| 13.4
| 141.5
| 16
| 2.1x1.6
| 3.2x2.4
| 4.3x3.2
|
CSWL20-250A
| 2.0x
| 0.75
| 13.4
| 112.4
| 16
| 1.6x1.2
| 2.4x1.8
| 3.2x2.4
|
CSWL10-250C
| 1.0x
| 1
| 13.4
| 115.8
| 16
| 3.2 x 2.4
| 4.8 x 3.6
| 6.4x4.8
|
CSWL15-250C
| 1.5x
| 1
| 13.4
| 141.5
| 16
| 2.1x1.6
| 3.2x2.4
| 4.3x3.2
|
CSWL20-250C
| 2.0x
| 0.5
| 9.3
| 112.4
| 16
| 1.6x1.2
| 2.4x1.8
| 3.2x2.4
|
