CSBH系列 雙遠心鏡頭(已停產)

抱歉，該產品已停產下架

• 全系列物方遠心定倍鏡頭，有多款工作距/倍率/CCD可供選擇

• 成像畫質完美，支持各款百萬像素數字相機

• 高對比，低畸變，超清晰，可內置同軸光照明

• 備有可變光欄規格，以達到分辨率與景深的Zui佳平

• 廣泛應用于高精度視覺定位等場合

  型號

  光學參數

  鏡頭外形

  像方視場(W x H)

  倍率

  工作距

  景深

  遠心度

  像面畸變

  分辨率

  特征

  長度

  Zui大外徑

  1/3"像面

  1/2"像面

  1/1.8"像面

  2/3"像面

  工作距65mm

  CSWH08-65AT

  0.8x

  65±3

  1.2

  ≤0.018°

  ≤0.2%

  8.5um

  物方遠心

  89.7

  26

  6X4.5

  8X6

  9X6.5

  11X8.25

  CSWH08-65CT

  0.8x

  65±3

  1.2

  ≤0.006°

  ≤0.2%

  8.5um

  物方遠心

  89.7

  26

  6X4.5

  8X6

  9X6.5

  11X8.25

  CSWH10-65AT

  1.0x

  65±3

  0.8

  ≤0.018°

  ≤0.2%

  7.5um

  物方遠心

  79.9

  26

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH10-65CT

  1.0x

  65±3

  0.8

  ≤0.011°

  ≤0.2%

  7.5um

  物方遠心

  79.9

  26

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH15-65AT

  1.5x

  65±3

  0.4

  ≤0.013°

  ≤0.2%

  5.3um

  物方遠心

  74.6

  26

  3.2X2.4

  4.3X3.2

  4.8X3.6

  5.9X4.4

  CSWH15-65CT

  1.5x

  65±3

  0.4

  ≤0.015°

  ≤0.2%

  5.3um

  物方遠心

  74.6

  26

  3.2X2.4

  4.3X3.2

  4.8X3.6

  5.9X4.4

  CSWH20-65AT

  2.0x

  65±3

  0.28

  ≤0.008°

  ≤0.2%

  4.6um

  物方遠心

  80

  26

  2.4X1.8

  3.2X2.4

  3.6X2.6

  4.4X3.3

  CSWH20-65CT

  2.0x

  65±3

  0.28

  ≤0.005°

  ≤0.2%

  4.6um

  物方遠心

  80

  26

  2.4X1.8

  3.2X2.4

  3.6X2.6

  4.4X3.3

  工作距110mm

  CSWH03-110AT

  0.3x

  110±2

  4

  ≤0.1°

  ≤0.1%

  20.1um

  物方遠心

  137.1

  43

  16X12

  21.3X16

  23.7X17.9

  CSWH03-110CT

  0.3x

  110±2

  4

  ≤0.1°

  ≤0.1%

  20.1um

  物方遠心

  137.1

  43

  16X12

  21.3X16

  23.7X17.9

  CSWH05-110AT

  0.5x

  110±2

  3

  ≤0.1°

  ≤0.35%

  10.3um

  物方遠心

  135.2

  34

  9.6X7.2

  12.8X9.6

  14.4X10.4

  17.6X13.2

  CSWH05-110AT-G

  0.5x

  110±2

  7.5

  ≤0.1°

  ≤0.35%

  10.3um

  物方遠心

  135.2

  34

  9.6X7.2

  12.8X9.6

  14.4X10.4

  17.6X13.2

  CSWH05-110CT

  0.5x

  110±2

  3

  ≤0.1°

  ≤0.35%

  10.3um

  物方遠心

  135.2

  34

  9.6X7.2

  12.8X9.6

  14.4X10.4

  17.6X13.2

  CSWH05-110CT-G

  0.5x

  110±2

  7.5

  ≤0.1°

  ≤0.35%

  10.3um

  物方遠心

  135.2

  34

  9.6X7.2

  12.8X9.6

  14.4X10.4

  17.6X13.2

  CSWH10-110AT

  1.0x

  110±2

  0.85

  ≤0.02°

  ≤0.3%

  5.8um

  物方遠心

  133.9

  28

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH10-110AT-G

  1.0x

  110±2

  3

  ≤0.02°

  ≤0.3%

  5.8um

  物方遠心

  133.9

  28

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH10-110CT

  1.0x

  110±2

  0.85

  ≤0.02°

  ≤0.3%

  5.8um

  物方遠心

  138.2

  28

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH10-110CT-G

  1.0x

  110±2

  3

  ≤0.02°

  ≤0.3%

  5.8um

  物方遠心

  138.2

  28

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH20-110AT

  2.0x

  110±2

  0.36

  ≤0.01°

  ≤0.52%

  5um

  物方遠心

  147.4

  28

  2.4X1.8

  3.2X2.4

  3.6X2.6

  4.4X3.3

  CSWH20-110AT-G

  2.0x

  110±2

  1.5

  ≤0.01°

  ≤0.52%

  5um

  物方遠心

  147.4

  28

  2.4X1.8

  3.2X2.4

  3.6X2.6

  4.4X3.3

  CSWH20-110CT

  2.0x

  110±2

  0.36

  ≤0.01°

  ≤0.52%

  5um

  物方遠心

  151.7

  28

  2.4X1.8

  3.2X2.4

  3.6X2.6

  4.4X3.3

  CSWH20-110CT-G

  2.0x

  110±2

  1.5

  ≤0.01°

  ≤0.52%

  5um

  物方遠心

  151.7

  28

  2.4X1.8

  3.2X2.4

  3.6X2.6

  4.4X3.3

  CSWH40-110AT

  4.0x

  110±2

  0.1

  ≤0.1°

  ≤0.1%

  4.5um

  物方遠心

  128.8

  28

  1.2X0.9

  1.6X1.2

  1.8X1.3

  2.2X1.7

  CSWH40-110CT

  4.0x

  110±2

  0.1

  ≤0.1°

  ≤0.1%

  4.5um

  物方遠心

  131.1

  28

  1.2X0.9

  1.6X1.2

  1.8X1.3

  2.2X1.7

  工作距130mm

  CSWH08-130AT

  0.8x

  130±2

  1.5

  ≤0.16°

  ≤0.4%

  8.5um

  物方遠心

  117.1

  28

  6x4.5

  8x6

  8.9x6.7

  11x8.3

  CSWH08-130AT-G

  0.8x

  130±2

  3.8

  ≤0.16°

  ≤0.4%

  8.5um

  物方遠心

  117.1

  28

  6x4.5

  8x6

  8.9x6.7

  11x8.3

  CSWH08-130CT

  0.8x

  130±2

  1.5

  ≤0.16°

  ≤0.4%

  8.5um

  物方遠心

  121.4

  28

  6x4.5

  8x6

  8.9x6.7

  11x8.3

  CSWH08-130CT-G

  0.8x

  130±2

  3.8

  ≤0.16°

  ≤0.4%

  8.5um

  物方遠心

  121.4

  28

  6x4.5

  8x6

  8.9x6.7

  11x8.3

  工作距145mm

  CSWH07-145AT

  0.7x

  145±3

  3.2

  ≤0.05°

  ≤0.6%

  13um

  物方遠心

  110.4

  28

  6.9x5.1

  9.1x6.9

  10.2x7.7

  12.6x9.4

  CSWH07-145AT-G

  0.7x

  145±3

  4.2

  ≤0.05°

  ≤0.6%

  13um

  物方遠心

  110.4

  28

  6.9x5.1

  9.1x6.9

  10.2x7.7

  12.6x9.4

  CSWH07-145CT

  0.7x

  145±3

  2.7

  ≤0.05°

  ≤0.6%

  13um

  物方遠心

  114.7

  28

  6.9x5.1

  9.1x6.9

  10.2x7.7

  12.6x9.4

  CSWH07-145CT-G

  0.7x

  145±3

  4.2

  ≤0.05°

  ≤0.6%

  13um

  物方遠心

  114.7

  28

  6.9x5.1

  9.1x6.9

  10.2x7.7

  12.6x9.4

  長工作距系列

  CSWH05-510AT

  0.5x

  510±3

  8

  /

  ≤0.3%

  13.8um

  百萬像素

  163.8

  26

  9.6X7.2

  12.8X9.6

  14.4X10.4

  17.6X13.2

  CSWH05-510CT

  0.5x

  510±3

  8

  /

  ≤0.3%

  13.8um

  百萬像素

  166.3

  26

  9.6X7.2

  12.8X9.6

  14.4X10.4

  17.6X13.2

  CSWH10-330AT

  1.0x

  330±3

  2.4

  ≤0.02°

  ≤0.4%

  16.3um

  物方遠心

  199.7

  26

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH10-330CT

  1.0x

  330±3

  2.4

  ≤0.02°

  ≤0.4%

  16.3um

  物方遠心

  197.6

  26

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH10-410AT

  1.0x

  410±3

  1.5

  /

  ≤0.35%

  10.4um

  百萬像素

  178.9

  26

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH10-410CT

  1.0x

  410±3

  1.5

  /

  ≤0.35%

  10.4um

  百萬像素

  182.2

  26

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH10-510AT

  1.0x

  510±3

  2

  /

  ≤0.2%

  13.8um

  百萬像素

  175

  26

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6

  CSWH10-510CT

  1.0x

  510±3

  2

  /

  ≤0.2%

  13.8um

  百萬像素

  178.5

  26

  4.8X3.6

  6.4X4.8

  7.2X5.2

  8.8X6.6
